Article |
Unit |
MAIVL600 |
MAIVL600H |
MAIVL800 |
MAIVL800H |
|
Processing |
|
|
|
|
|
|
Maximum cutting diameter for disc parts |
mm |
Ø600 |
Ø500 |
Ø800 |
Ø700 |
|
Maximum cutting diameter for shaft parts |
mm |
Ø600 |
Ø500 |
Ø620 |
Ø620 |
|
Maximum cutting height |
mm |
600 |
500 |
650 |
600 |
|
Spindle |
|
|
|
|
|
|
Spindle nose |
mm |
A₂-8 |
A₂-8 |
A₂-11 |
A₂-11 |
|
Front spindle bearing ID |
mm |
Ø140 |
Ø140 |
Ø180 |
Ø180 |
|
Spindle speed range |
rpm |
100-2000 |
100-2000 |
50-1800 |
50-1800 |
|
Spindle speed steps |
|
continuous |
continuous |
2 steps, continuous in each one |
2 steps, continuous in each one |
|
Chuck diameter |
inches |
18 |
18 |
21 |
21 |
|
Tour |
|
|
|
|
|
|
X axis travel |
mm |
-30;+300 |
-30;+300 |
-60;460 |
-30;+420 |
|
Z axis travel |
mm |
600 |
600 |
650 |
650 |
|
Preview |
|
|
|
|
|
|
Rapid feed for the X axis |
m/min |
10 |
10 |
12 |
12 |
|
Fast feed for Z axis |
m/min |
12 |
12 |
16 |
16 |
|
Lathe |
|
|
|
|
|
|
Tool holder type |
|
Hydraulic |
Live tool |
Hydraulic |
Live tool |
|
Tool holder stations |
pieces |
8 |
12 |
8 |
12 |
|
Tool Shank Size (Square) |
mm |
25×25 |
25×25 |
32×32 |
25×25 |
|
Tool Shank Size (Round) |
mm |
Ø40 |
Ø40 |
Ø50 |
Ø40 |
|
Others |
|
|
|
|
|
|
Main engine power |
kw |
18.5/22 |
18.5/22 |
22/26 |
22/26 |
|
Live Tool Servo Motor Power |
kw |
|
3.7/5.5 |
|
3.7/5.5 |
|
Hydraulic motor |
kw |
1.5 |
1.5 |
1.5 |
1.5 |
|
Coolant pump motor |
w |
370 |
370 |
370×2 |
370 |
|
Overall dimensions (L×W×H) |
mm |
2150×3210×3200 |
2150×3210×3200 |
3060×3530×3350 |
3060×3530×3350 |
|
Net weight |
kg |
8000 |
8000 |
11500 |
11500 |
The specifications, text descriptions, confiqurations, pictures, colors, etc.
given herein are subject to alternation without notice and thus wthout any obligation.
