Item |
Unit |
MAIVM1060VA |
MAIVM1060VC |
|
Processing range |
|
|
|
|
X/Y/Z axis travel |
mm |
1000/600/600 |
1100/600/600 |
|
A axis rotation angle |
Deg. |
360 |
－ |
|
B axis rotation angle |
Deg. |
±110 |
±110 |
|
C axis rotation angle |
Deg. |
－ |
360 |
|
Distance from spindle centerline to column surface |
mm |
640 |
640 |
|
Distance from spindle centerline to worktable |
mm |
395～995 |
395～995 |
|
Distance from spindle nose to worktable |
mm |
150-750 |
150-750 |
|
Distance from A axis centerline to worktable surface |
mm |
160 |
－ |
|
Work table |
|
|
|
|
Rotary table diameter |
mm |
Φ250（A axis） |
Φ500（C axis） |
|
T-slot(width x number x spacing) |
mm |
18×5×100 |
18×5×125 |
|
Max. load of rotary table |
kg |
250（with tailstock） |
500 |
|
Rectangular table size |
mm |
1700×600 |
1250×620 |
|
Max. load of rectangular table |
kg |
800 |
800 |
|
Feed system |
|
|
|
|
X/Y/Z axis rapid feed |
m/min |
30/30/30 |
30/30/30 |
|
X/Y/Z axis torque |
Nm |
27/27/27 |
27/27/27 |
|
A-axis Max. speed |
rpm |
50 |
－ |
|
B-axis Max. speed |
rpm |
16 |
16 |
|
C-axis Max. speed |
rpm |
－ |
33 |
|
A axis allowable cutting force |
Kgf-m |
112 |
－ |
|
B axis allowable cutting force |
Kgf-m |
100 |
100 |
|
C axis allowable cutting force |
Kgf-m |
－ |
120 |
|
Spindle system |
|
|
|
|
Spindle drive mode |
|
Built-in type |
Built-in type |
|
Spindle Max. speed |
rpm |
15000 |
15000 |
|
Spindle rated power |
kW |
21 |
21 |
|
Spindle rated torque |
Nm |
76 |
76 |
|
Tool shank specifications |
|
HSK-A63/BBT40 |
HSK-A63/BBT40 |
|
Tool changing system (disk type) |
|
|
|
|
Tool magazine capacity |
pcs |
24 |
24 |
|
Tool change time (T-T) |
Sec. |
2 |
2 |
|
Accuracy |
|
|
|
|
X/Y/Z axis repeat positioning accuracy |
mm |
≤0.006 |
≤0.006 |
|
X/Y/Z axis positioning accuracy |
mm |
≤0.01 |
≤0.01 |
|
A/C, B axis repeat positioning accuracy |
mm |
≤6 |
≤6 |
|
A/C, B axis positioning accuracy |
mm |
≤12 |
≤12 |
|
A/C, B Min. indexing unit |
Deg. |
0.001 |
0.001 |
|
Others |
|
|
|
|
CNC system |
|
Siemens one |
Siemens one |
|
Machine weight |
kg |
6500 |
7500 |
