Item |
Unit |
MAI0632A |
MAI0636A |
|
Processing |
|
|
|
|
Max. swing Dia. over bed |
mm |
Ø330 |
Ø360 |
|
Max. swing Dia. over slide |
mm |
Ø198 |
Ø230 |
|
Max. swing Dia. in gap |
mm |
Ø476 |
Ø506 |
|
Width of bed |
mm |
186 |
186 |
|
Max. length of workpiece(two centers) |
mm |
500/750/1000 |
500/750/1000 |
|
Spindle |
|
|
|
|
Taper of spindle bore |
|
M.T.No.5 |
M.T.No.5 |
|
Spindle bore |
mm |
Ø38 |
Ø38 |
|
Steps of spindle speed |
|
8 |
8 |
|
Range of spindle speed |
rpm |
70~2000 |
70~2000 |
|
Spindle nose |
|
D4 |
D4 |
|
Thread |
|
|
|
|
Metric thread |
|
0.45~10mm/27 |
0.45~10mm/27 |
|
Inch thread |
|
3½~80T.P.I. /36 |
3½~80T.P.I. /36 |
|
Feed |
|
|
|
|
Range of longitudinal feed |
mm/r |
0.067~1.019 |
0.067~1.019 |
|
Range of cross feed |
mm/r |
0.018~0.275 |
0.018~0.275 |
|
Leadscrew |
|
|
|
|
leadscrew Dia. |
mm |
Ø 22 |
Ø 22 |
|
leadscrew pitch |
mm |
3 |
3 |
|
Tailstock |
|
|
|
|
Travel of tailstock quill |
mm |
95 |
95 |
|
Dia. of tailstock quill |
mm |
Ø32 |
Ø32 |
|
Taper of tailstock quill |
|
M.T.No.3 |
M.T.No.3 |
|
Power of main motor |
kW |
1.5 |
1.5 |
|
Coolant pump motor power |
kW |
0.04 |
0.04 |
|
Overall dimensions (L×W×H) |
mm |
1295/1545/1795×695×1270 |
1295/1545/1795×695×1286 |
|
Net weight |
kg |
400 |
630 |
The specifications, text descriptions, confiqurations, pictures, colors, etc.
given herein are subject to alternation without notice and thus wthout any obligation.
