MAI6140ZK/6240ZK/6146ZK/6246ZK

Manual Lathe

The guideways and all gears in the headstock are hardened and precision ground.The spindle system is high in rigidity and accuracy.The machines have powerful headstock gear train, high rotating accuracy and smooth running with low noise.

Item	Unit	MAI6140ZK	MAI6240ZK	MAI6146ZK	MAI6246ZK
Processing
Max. swing Dia. over bed	mm	Φ400	Φ400	Φ460	Φ460
Max. swing Dia. over carriage	mm	Φ255	Φ255	Φ275	Φ275
Max. swing Dia. in gap(only for 62 series)	mm	-	Φ570	-	Φ630
Width of bed	mm	312	312	312	312
Max.length of workpiece	mm	750/1000/1500	750/1000/1500	750/1000/1500	750/1000/1500
Maximum turned length	mm	650/900/1400	650/900/1400	650/900/1400	650/900/1400
Effective gap length	mm	200	200	200	200
Spindle
Spindie nose		D6	D6	D6	D6
Spindle bore	mm	Φ52	Φ52	Φ52	Φ52
Taper of bore		M.T.No.6	M.T.No.6	M.T.No.6	M.T.No.6
Steps of spindle speed		12	12	12	12
Ranges of spindle speed	rpm	40~1800	40~1800	40~1800	40~1800
Thread cutting
Metric range/No.		0.5～20mm/24	0.5～20mm/24	0.5～20mm/24	0.5～20mm/24
Inch range/No.		72~1⅝T.P.I/61	72~1⅝T.P.I/61	72~1⅝T.P.I/61	72~1⅝T.P.I/61
D.P.Range/No.		96~3¼D.P/45	96~3¼D.P/45	96~3¼D.P/45	96~3¼D.P/45
Module range/No.		0.25~10M.P/20	0.25~10M.P/20	0.25~10M.P/20	0.25~10M.P/20
Range of feeds
Longitudinal	mm	0.04~2.46	0.04~2.46	0.04~2.46	0.04~2.46
Cross	mm	0.03~1.23	0.03~1.23	0.03~1.23	0.03~1.23
Tailstock sleeve
External Dia.	mm	Φ60	Φ60	Φ60	Φ60
Taper of bore		M.T.No.4	M.T.No.4	M.T.No.4	M.T.No.4
Max.traverse	mm	120	120	120	120
Max.travel of compound rest	mm	130	130	130	130
Max.cross slide travel	mm	240	240	240	240
Max. size of tool shank(WxH)	mm	25×25	25×25	25×25	25×25
Power of main motor(double speeds)	kW	4/5.5	4/5.5	4/5.5	4/5.5
Overall dimensions(L×W×H)	mm	2140/2360/2860×1000×1230	2140/2360/2860×1000×1230	2140/2360/2860×1000×1250	2140/2360/2860×1000×1250
Net weight	kg	1650/1730/1890	1730/1810/1970	1700/1780/1940	1780/1860/2020

The specifications, text descriptions, confiqurations, pictures, colors, etc. given herein are subject to alternation without notice and thus wthout any obligation.
